CAN: 0 In stock
USA: 55 In stock
MOQ: 1
PDF generation may take time depending on details of the product.
| Thread Size - Inch | 5/8 |
| Thread Type | UNF |
| Threads Per Inch | 18 |
| Thread Limit | H3 |
| Chamfer Type | Plug (4P) |
| Major Diameter - Inch | 0.625 |
| Thread Length - Inch (Lc) | 0.728 |
| Tap Drill Size Min - Inch | 0.565 |
| Tap Drill Size Max - Inch | 0.578 |
| Neck Length - Inch (L1) | 2.125 |
| Overall Length - Inch (L) | 3.813 |
| Square Length - Inch (Ik) | 0.5625 |
| Shank Diameter - Inch (d) | 0.48 |
| Square Width - Inch (k) | 0.36 |
| STI Thread | No |
| Substrate | HSS |
| Surface Treatment | Steam Oxide |
| Coolant Thru | No |
| Number of Flutes | 4 |
| Cutting Direction | RH |
| Helix Angle - Degree | 45 |
| Helix Direction | RH |
| Interrupted Thread | No |
| View Catalog Page | Here |
