CAN: 0 In stock
USA: 481 In stock
MOQ: 1
PDF generation may take time depending on details of the product.
| Thread Size - Number | No. 4 |
| Thread Type | UNC |
| Threads Per Inch | 40 |
| Thread Limit | H3 |
| Chamfer Type | Modified Bottom (2.5P) |
| Major Diameter - Inch | 0.112 |
| Thread Length - Inch (Lc) | 0.295 |
| Tap Drill Size Min - Inch | 0.09925 |
| Tap Drill Size Max - Inch | 0.1018 |
| Neck Length - Inch (L1) | 0.559 |
| Overall Length - Inch (L) | 1.875 |
| Square Length - Inch (Ik) | 0.1875 |
| Shank Diameter - Inch (d) | 0.141 |
| Square Width - Inch (k) | 0.11 |
| STI Thread | No |
| Substrate | HSS-CO |
| Surface Treatment | Steam Oxide |
| Coolant Thru | No |
| Cutting Direction | RH |
| Interrupted Thread | No |
| View Catalog Page | Here |
| STP Drawing | Download |
| Notes | Other coatings are available upon request. |
