THREADING/STYLE/SPIRAL POINT/344STI,THREADING/STYLE/STI/344STI - STI

Ideal for Difficult to Machine Materials

EDP: 34400408
M4x0.7 STI D3 3S/P PLUG EXO VC10 V
Description
P

Steel

Alloy Steels : 4140; 4340
Die Steels

Good
Best
M

Stainless Steel

Stainless Steels : 17-4PH
Stainless Steels : 400

Good
Best
H

Hardened Steel

Hardened Steels : 35 HRC
Hardened Steels : 35-45 HRC

Good
Best
S

Heat Resistant Super Alloy

Nickel Alloy : Inconel
Titanium : 6AL4V (30HRC)

Good
Best
P

Steel

Alloy Steels : 4140; 4340
Die Steels

Good
Best
M

Stainless Steel

Stainless Steels : 17-4PH
Stainless Steels : 400

Good
Best
H

Hardened Steel

Hardened Steels : 35 HRC
Hardened Steels : 35-45 HRC

Good
Best
S

Heat Resistant Super Alloy

Nickel Alloy : Inconel
Titanium : 6AL4V (30HRC)

Good
Best
Description
EXOTAP VC-10 is the premium solution for tapping helicoil (STI) threads in difficult to machine materials.
Features & Benefits
OSG V-Coating Increased hardness, lubricity & wear resistance
Premium Powdered Metal VC-10 substrate Increased hardness for longer life
Spiral Point For through hole applications
Steam Oxide surface treatment S/O increases mechanical lubricity
Stocked
ALTERNATIVE PRODUCT

CAN: 0 In stock

USA: 53 In stock

MOQ: 1

Add to List
Thread Size - MetricM4
Thread TypeM STI
Pitch0.7
Thread LimitD3
Chamfer TypePlug (5P)
Major Diameter - Metric4
Thread Length - Metric (Lc)9.9314
Tap Drill Size Min - Metric4.152
Tap Drill Size Max - Metric4.332
Neck Length - Metric (L1)22.352
Overall Length - Metric (L)60.5
Shank Diameter - Metric (d)4.9276
Square Length - Metric (Ik)6.35
Square Width - Metric (k)3.8608
STI ThreadYes
SubstrateVC-10
Surface TreatmentV
Coolant ThruNo
Number of Flutes3
Cutting DirectionRH
Helix Angle - Degree0
Interrupted ThreadNo
View Catalog PageHere

Downloads


Basic 3D Model (STP)

2D Drawing(DXF)
