THREADING/STYLE/SPIRAL FLUTE/347

EXOTAP VA-3 OIL-V-SFT

Coolant-Through Taps Designed for Stainless Steel

EDP: 34702408
M24X3.0 D8 4FX MOD-BOTT EXOTAP VA3 DIN OH V
Description
Taps_-_Tap_-_EXOTAP_VA-3_-_List_347_-_Catalog
P

Steel

Medium Carbon Steel : 1035; 1045
Low Carbon Steel : 1010; 1018
High Carbon Steel : 1065
Good
Best
M

Stainless Steel

Stainless Steels : 300
Stainless Steels : 400
Stainless Steels : 17-4PH
Good
Best
P

Steel

Medium Carbon Steel : 1035; 1045
Low Carbon Steel : 1010; 1018
High Carbon Steel : 1065
Good
Best
M

Stainless Steel

Stainless Steels : 300
Stainless Steels : 400
Stainless Steels : 17-4PH
Good
Best
Description
EXOTAP VA-3 is the premium solution for tapping in stainless steels.
Features & Benefits
HSSE material Increased wear resistance
OSG V-Coating Increased hardness, lubricity & wear resistance
Spiral Flute For blind hole applications
Steam Oxide surface treatment S/O increases mechanical lubricity
Stocked
ALTERNATIVE PRODUCT
VIEW PRODUCT
CONTACT US

CAN: 0 In stock

USA: 20 In stock

MOQ: 1

Preview PDF

PDF generation may take time depending on details of the product.

Thread Size - MetricM24
Thread TypeM
Pitch3
Thread LimitD8
Chamfer TypeModified Bottom (2.5P)
Major Diameter - Metric24
Thread Length - Metric (Lc)24
Tap Drill Size Min - Metric20.752
Tap Drill Size Max - Metric21.252
Neck Length - Metric (L1)68.4
Overall Length - Metric (L)160
Shank Diameter - Metric (d)19.304
Square Length - Metric (Ik)19.05
Square Width - Metric (k)14.478
STI ThreadNo
SubstrateHSSE
Surface TreatmentV
Coolant ThruYes
Number of Flutes4
Cutting DirectionRH
Helix Angle - Degree45
Helix DirectionRH
Interrupted ThreadNo
View Catalog PageHere
