THREADING/STYLE/SPIRAL POINT/11017

Premium Design for a Wide Range of Materials

EDP: 1101700808
5/16-18 H3 3S/P PLUG HY-PRO DIN TICN
Description
P

Steel

Alloy Steels : 4140; 4340
Die Steels
High Carbon Steel : 1065
Low Carbon Steel : 1010; 1018
Medium Carbon Steel : 1035; 1045

Good
Best
M

Stainless Steel

Stainless Steels : 300
Stainless Steels : 400
Stainless Steels : 17-4PH

Good
Best
K

Cast Iron

Cast Iron

Good
Best
H

Hardened Steel

Hardened Steels : 35 HRC

Good
Best
P

Steel

Alloy Steels : 4140; 4340
Die Steels
High Carbon Steel : 1065
Low Carbon Steel : 1010; 1018
Medium Carbon Steel : 1035; 1045

Good
Best
M

Stainless Steel

Stainless Steels : 300
Stainless Steels : 400
Stainless Steels : 17-4PH

Good
Best
K

Cast Iron

Cast Iron

Good
Best
H

Hardened Steel

Hardened Steels : 35 HRC

Good
Best
Description
HY-PRO V DIN is the premium solution for unsurpassed performance in difficult to machine materials. This premium spiral point tap is made from vanadium high speed steel.
Features & Benefits
HSSE material Increased wear resistance
OSG V-Coating Increased hardness, lubricity & wear resistance
Spiral Point For through hole applications
DIN Overall Length Provides additional reach capability
Stocked
ALTERNATIVE PRODUCT
Loading...

MOQ: 1

Add to List
Thread Size - Inch5/16
Thread TypeUNC
Threads Per Inch18
Thread LimitH3
Chamfer TypePlug (4P)
Major Diameter - Inch0.3125
Thread Length - Inch (Lc)0.669
Tap Drill Size Min - Inch0.252
Tap Drill Size Max - Inch0.265
Neck Length - Inch (L1)1.382
Overall Length - Inch (L)3.543
Square Length - Inch (Ik)0.375
Shank Diameter - Inch (d)0.318
Square Width - Inch (k)0.238
STI ThreadNo
SubstrateHSSE
Surface TreatmentV
Coolant ThruNo
Number of Flutes3
Cutting DirectionRH
Helix Angle - Degree0
Interrupted ThreadNo
View Catalog PageHere

Downloads


Basic 3D Model (STP)

2D Drawing(DXF)
