DRILLING/SOLID - DRILLING/JOBBER/HP355

HY-PRO CARB ALD-HO-5D

Performance Carbide Drills for Non-Ferrous Materials

EDP: 111512100
12.10MM HYPRO CARB ALD-HO-5D
Description
Drills_-_Drill_-_HY-PRO_CARB_ALD-HO_-_List_HP355
N

Non-Ferrous

Aluminum : 6061; 7075
Aluminum : Casting
Good
Best
N

Non-Ferrous

Aluminum : 6061; 7075
Aluminum : Casting
Good
Best
Description
The HY-PRO CARB carbide drill series is an ideal blend of performance and cost-efficiency. HY-PRO CARB ALD is capable of stable chip formation & evacuation, and good quality holes over a wide range of feed rates, enabling high efficiency drilling in aluminum alloy and other non-ferrous materials.
Features & Benefits
Double Margin Improved stability & hole straightness.
Polished Flutes Smooth chip evacuation, and less BUE at the cutting edge.
Straight Cutting Edge Lower thrust force at higher feeds.
X-Thinning & R-Gash Sharp & smoothcutting at the center.
Made to Order
ALTERNATIVE PRODUCT
VIEW PRODUCT
CONTACT US

Made to Order Item

Preview PDF

PDF generation may take time depending on details of the product.

Diameter - Metric (D)12.1
Diameter - Inch (D)0.47638
Flute Length - Metric (FL)77
Overall Length - Metric (L)124
Shank Diameter - Metric (d)14
Cutting Diameter Tolerance - Inch+0.0003 / +0.0010
Cutting Diameter Tolerance - Metric+0.007 / +0.025
Cutting Diameter Tolerance Specificationm7
SubstrateCarbide
Surface TreatmentBRIGHT
Length of Cut - SpecificationJOBBER
Drilling L/D Ratio (xD)5
Helix Angle - Degree30
Point Angle - Degree (α)130
Point ThinningX Thinning
Helix DirectionRH
Cutting DirectionRH
Coolant ThruYes
Number of Flutes2
Shank Toleranceh6
View Catalog PageHere
View Speed and Feed PageHere
