CAN: 0 In stock
USA: 26 In stock
MOQ: 1
PDF generation may take time depending on details of the product.
| Thread Size - Inch | 1 |
| Thread Type | NPT, ANPT |
| Threads Per Inch | 11.5 |
| Projection - Inch (P) | 0.578 |
| Major Diameter - Inch | 1 |
| Thread Length - Inch (Lc) | 1.751 |
| Tap Drill Size Min - Inch | 1.140625 |
| Overall Length - Inch (L) | 3.751968 |
| Square Length - Inch (Ik) | 0.8125 |
| Shank Diameter - Inch (d) | 1.125 |
| Square Width - Inch (k) | 0.843 |
| STI Thread | No |
| Substrate | HSS |
| Surface Treatment | TiCN |
| Coolant Thru | No |
| Number of Flutes | 5 |
| Cutting Direction | RH |
| Helix Angle - Degree | 15 |
| Helix Direction | RH |
| Interrupted Thread | No |
| View Catalog Page | Here |
| Notes | Other coatings are available upon request. |
