Ideal for Wind Energy Applications
Steel
Stainless Steel
Cast Iron
Hardened Steel
Steel
Stainless Steel
Cast Iron
Hardened Steel
CAN: 0 In stock
USA: 37 In stock
MOQ: 1
PDF generation may take time depending on details of the product.
| Thread Size - Metric | M33 |
| Thread Type | M |
| Pitch | 3.5 |
| Thread Limit | D10 |
| Chamfer Type | Modified Bottom (2.5P) |
| Major Diameter - Metric | 33 |
| Thread Length - Metric (Lc) | 28 |
| Tap Drill Size Min - Metric | 29.211 |
| Tap Drill Size Max - Metric | 29.771 |
| Overall Length - Metric (L) | 250 |
| Shank Diameter - Metric (d) | 28.1432 |
| Square Length - Metric (Ik) | 26.9875 |
| Square Width - Metric (k) | 21.1074 |
| STI Thread | No |
| Substrate | HSSE |
| Surface Treatment | Steam Oxide |
| Coolant Thru | No |
| Number of Flutes | 5 |
| Cutting Direction | RH |
| Helix Angle - Degree | 45 |
| Helix Direction | RH |
| Interrupted Thread | No |
| View Catalog Page | Here |
| Notes | +0.005" available for threads that will be heat treated after tapping. |
