DRILLING/SOLID - DRILLING/REAMERS/300D

OSG CHUCKING REAMER

Standard Carbide Reamer for General Machining Applications

EDP: 300-2280
CARBIDE #1 ST/FLT REAMER
Description
Drills_-_Drill_-_CARBIDE_CHUCKING_REAMER_-_List_300_-_Catalog
P

Steel

Alloy Steels : 4140; 4340
Low Carbon Steel : 1010; 1018
Medium Carbon Steel : 1035; 1045
Good
Best
M

Stainless Steel

Stainless Steels : 17-4PH
Stainless Steels : 300
Stainless Steels : 400
Good
Best
K

Cast Iron

Cast Iron
Good
Best
N

Non-Ferrous

Aluminum : 6061; 7075
Aluminum : Casting
Good
Best
P

Steel

Alloy Steels : 4140; 4340
Low Carbon Steel : 1010; 1018
Medium Carbon Steel : 1035; 1045
Good
Best
M

Stainless Steel

Stainless Steels : 17-4PH
Stainless Steels : 300
Stainless Steels : 400
Good
Best
K

Cast Iron

Cast Iron
Good
Best
N

Non-Ferrous

Aluminum : 6061; 7075
Aluminum : Casting
Good
Best
Description
The solid carbide chucking reamer is one of many value-minded products within the OSG Standard Carbide family of products. An economical solution without sacrificing consistent tolerancing and precision.
Features & Benefits
Right Hand Cutting (Std)
Solid Carbide Solid carbide ensures better wear resistance for long stable tool life
Straight Flute High precision, excellent finishes.
Stocked
ALTERNATIVE PRODUCT
VIEW PRODUCT
CONTACT US

CAN: 0 In stock

USA: 0 In stock

MOQ: 1

Preview PDF

PDF generation may take time depending on details of the product.

Diameter - Metric (D)5.791
Diameter - Wire Gage (D)1
Diameter - Inch (D)0.228
Flute Length - Inch (FL)1
Overall Length - Inch (L)3
Shank Diameter - Inch (d)0.2188
Cutting Diameter Tolerance - Inch+0.0001 / +0.0004
Cutting Diameter Tolerance - Metric+0.0025 / +0.0102
SubstrateCarbide
Surface TreatmentBRIGHT
Helix Angle - Degree0
Cutting DirectionRH
Coolant ThruNo
Number of Flutes4
View Catalog PageHere
View Speed and Feed PageHere
