MILLING/SOLID - MILLING/SQUARE END/593,MILLING/SOLID - MILLING/TAPERED/593 - TAPERED

OSG

High Performance Cobalt HSS End Mills for General Milling Applications

EDP: 5931100
5/64" DIA L/C 1/2" 2 DEG TAPER
Description
P

Steel

Alloy Steels : 4140; 4340
Die Steels
High Carbon Steel : 1065
Low Carbon Steel : 1010; 1018
Medium Carbon Steel : 1035; 1045

Good
Best
M

Stainless Steel

Stainless Steels : 17-4PH
Stainless Steels : 300
Stainless Steels : 400

Good
Best
K

Cast Iron

Cast Iron

Good
Best
N

Non-Ferrous

Aluminum : 6061; 7075
Aluminum : Casting

Good
Best
H

Hardened Steel

Hardened Steels : 35 HRC
Hardened Steels : 35-45 HRC

Good
Best
S

Heat Resistant Super Alloy

Titanium : 6AL4V (30HRC)

Good
Best
P

Steel

Alloy Steels : 4140; 4340
Die Steels
High Carbon Steel : 1065
Low Carbon Steel : 1010; 1018
Medium Carbon Steel : 1035; 1045

Good
Best
M

Stainless Steel

Stainless Steels : 17-4PH
Stainless Steels : 300
Stainless Steels : 400

Good
Best
K

Cast Iron

Cast Iron

Good
Best
N

Non-Ferrous

Aluminum : 6061; 7075
Aluminum : Casting

Good
Best
H

Hardened Steel

Hardened Steels : 35 HRC
Hardened Steels : 35-45 HRC

Good
Best
S

Heat Resistant Super Alloy

Titanium : 6AL4V (30HRC)

Good
Best
Description
High Performance Cobalt HSS End Mills for General Milling Applications
Features & Benefits
Stocked
SUBSTITUTE PRODUCT

CAN: 0 In stock

USA: 29 In stock

MOQ: 1

Add to List
Diameter - Fractional Size (D)5/64
Diameter - Inch (D)0.078125
Length of Cut - Inch (Lc)0.5
Length of Cut - SpecificationEXTRA LONG
Overall Length - Inch (L)1.75
Shank Diameter - Inch (d)0.1875
SubstrateHSS-CO
Helix Angle - Degree25
Helix DirectionRH
Mill TypeSingle End
Number of Flutes3
Surface TreatmentBRIGHT
Weldon FlatYes
Cutting DirectionRH
Cutting TypeCenter Cutting
Coolant ThruNo
End Cut TypeSquare End
Taper Angle Tolerance - Degree+0 / -10'
Type (feature)Tapered
View Catalog PageHere
View Speed and Feed PageHere
NotesOther coatings available upon request.
