THREADING/HOLDERS - THREADING/SYNCHROMASTER HOLDERS/9950

Synchronized Tap Holder Designed to Maximize Performance

EDP: 79926
SYNCHROMASTER TAP HOLDER CAT40-SMH16-90
Description
Holders_-_SynchroMaster_Tap_Holder_-_List_9950_-_Catalog_-_Type_2
Description
Synchronized Tap Holder Designed to Maximize Performance
Features & Benefits
1-Part Construction
ER16 & ER32 Sealed Collets Micro compensation reduces cutting force & maximizes tap performance
Metal Flexure Mechanism
Stocked
ALTERNATIVE PRODUCT
VIEW PRODUCT

CAN: 0 In stock

USA: 17 In stock

MOQ: 1

Add to List

Preview PDF

PDF generation may take time depending on details of the product.

Body Diameter - Metric (D3)32
Overall Length - Metric (L)90
DesignationCAT40-SMH16-90
Type2
Collet TypeER16GH, ER16GHC
View Catalog PageHere
View Speed and Feed PageHere
NotesCollet and spanner are sold seperately. Please use a machine with synchronous feed capability.
