{"Number of Flutes":["4","5","6"],"Chamfer Length - Inch":["0.246062","0.295275","0.344488","0.3937","0.442913","0.19685"],"Square Width - Metric (k)":["12.4206","14.478","17.0688","19.4564","21.1074","23.495","27.2288","9.144"],"Major Diameter - Metric":["20","24","27","30","33","36","42","16"],"Overall Length - Metric (L)":["140","200","160","180","250","300","110"],"Shank Diameter - Metric (d)":["16.5608","19.304","22.7584","25.9334","28.1432","31.3182","36.322","12.192"],"Tap Drill Size Max - Metric":["17.744","21.252","24.252","26.771","29.771","32.27","37.799","14.21"],"Pitch":["2.5","3","3.5","4","4.5","2"],"Tap Drill Size Min - Metric":["17.294","20.752","23.752","26.211","29.211","31.67","37.129","13.835"],"Neck Length - Metric (L1)":["73","103","88","108","138","93","128","118","143","98","148","58"],"Square Length - Metric (Ik)":["17.4625","19.05","22.225","25.4","26.9875","28.575","31.75","14.2875"],"Thread Length - Metric (Lc)":["20","24","28","32","36","16"],"View Catalog Page":"Here","Alloy Steels : 4140; 4340":"P; Best","Cast Iron":"K; Best","Chamfer Type":"Modified Bottom (2.5P)","Brand":"HY-PRO TAP","Coolant Thru":"No","Cutting Speed (SFM) - Alloy Steels : 4140; 4340":"20-50","Cutting Speed (SFM) - Cast Iron":"25-75","Cutting Speed (SFM) - Low Carbon Steel : 1010; 1018":"25-80","Hardened Steels : 35-45 HRC":"H; Good","Cutting Speed (SFM) - Die Steels":"15-20","Notes":"+0.005\" available for threads that will be heat treated after tapping.","Cutting Speed (SFM) - Stainless Steels : 17-4PH":"15-20","Full Description":"HY-PRO HXL-W Taps Horizontal Tapping Solutions for the Wind Energy Industry","Cutting Direction":"RH","Helix Angle - Degree":"15","Cutting Speed (SFM) - Hardened Steels : 35 HRC":"15-35","Die Steels":"P; Good","Cutting Speed (SFM) - Hardened Steels : 35-45 HRC":"8-15","List Name":"HXL-W-SFT","Cutting Speed (SFM) - High Carbon Steel : 1065":"20-45","Interrupted Thread":"No","Cutting Speed (SFM) - Stainless Steels : 300":"20-45","Cutting Speed (SFM) - Stainless Steels : 400":"20-45","Web Literature 2":"800183CA-V3","Cutting Speed (SFM) - Medium Carbon Steel : 1035; 1045":"20-50","Web Literature 1":"8002024CA-TP,144","Helix Direction":"RH","Meets 2B Class of Fit":"No","Product Category":"Spiral Flute","Meets 3B Class of Fit":"No","Hardened Steels : 35 HRC":"H; Best","High Carbon Steel : 1065":"P; Best","Web Literature 4":"800389CA","Thread Type":"M","Low Carbon Steel : 1010; 1018":"P; Best","Thread Limit":["D8","D9","D10","D11","D18","D19","D20","D21","D17","D7"],"Medium Carbon Steel : 1035; 1045":"P; Best","Stainless Steels : 17-4PH":"M; Good","Meets 4H Class of Fit":["Yes","No"],"Stainless Steels : 300":"M; Good","Meets 6H Class of Fit":["Yes","No"],"Surface Treatment":"Steam Oxide","Stainless Steels : 400":"M; Good","Thread Size - Metric":["M20","M24","M27","M30","M33","M36","M42","M16"],"Substrate":"HSSE","Units":"Metric","Product Overview":"HSS-Va, Extended Length, 6H, 6H+ 0.005\"","Short Description":"Ideal for Wind Energy Applications","STI Thread":"No","Diameter-Sizes":"-","Flute-Sizes":"-","Neck-Sizes":"58mm - 148mm","Taper-Sizes":"-","Overall-Sizes":"110mm - 300mm","Shank-Sizes":"12.192mm - 36.322mm","Images":["https://res.cloudinary.com/osg-usa-inc/image/upload/f_jpg,q_auto//Products%2FThreading%2FStyle%2FSpiral%20Flute%2FList%2013116/Taps_-_Tap_-_HY-PRO_HXL-W_-_List_13116_-_Spiral_Fluted_Taps"],"Friendly Name":"13116"}
